RKS.060.25.1534 turntable bearing swivel ring 1449X1619x68mm ball bearing without gear

Large Image : RKS.060.25.1534 turntable bearing swivel ring 1449X1619x68mm ball bearing without gear

Product Details:

Place of Origin:	Made In China
Brand Name:	JHB or OEM
Certification:	Quality certificate
Model Number:	RKS.060.25.1534

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	USD2000
Packaging Details:	strong wooden case
Delivery Time:	35 days
Payment Terms:	T/T, Western Union, L/C
Supply Ability:	2000PCS/Month

Contact Now

Detailed Product Description

Material:	50Mn	Ball Material:	GCr15
Seal Material:	NBR	Lubrication:	Grease
Soft Zone:	Yes	Quality Guarantee:	1 Year

RKS.060.25.1534 turntable bearing swivel ring 1449X1619x68mm

RKS.060.25.1534 slewing bearings are large-size rolling bearings that can accommodate axial,
radial and moment loads acting either singly or in combination and in any direction. They
can perform both slewing (oscillating) move- ments as well as rotational movements.
Basically, a slewing bearing consists of an inner ring , an outer ring and rolling elements − balls or cylindrical rollers − that are separated by polyamidespacers .

The rings, one of which usually incorporates a gear , are provided with holes to accommodate attachment bolts. The holes may be threaded. Generally, only the raceways in the rings are hardened and precision-ground. Integral seals made of acrylonitrile-butadiene rubber (NBR) keep the lubricant in, and contaminants out of the bearing. Slewing bearings are re lubricated.

RKS.060.25.1534 turntable bearing swivel ring 1449X1619x68mm specification as following:

Turntable bearing type	RKS.060.25.1534
Bearing structure	Four point contact ball bearing
Bearing size	1449X1619x68mm
Outer diameter	1619mm
Inner diameter	1449mm
Height	68mm
Weight:	155KGS
Material	Steel 50Mn 42CrMo
Rolling	Ball
Quality guarantee	1 year
Gear/teeth	Without gear
Delivery time	30 days
