The Twin Screw Extruder Gearbox Use Bearing F-87920-100-T8AR In Stock
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Material: | Steel GCr15SiMn | Structure: | Thrust Roller Bearing |
|---|---|---|---|
| Cage Material: | Brass/Nylon | Rolling Elements: | Roller |
| Precision Grade: | P5 Grade | Application: | Single And Twin Screw Extruders In The Rubber And Plastics |
| Lubrication: | Oil Lubrication | HS Code: | 8482500090 |
The twin screw extruder gearbox use bearing F-87920-100-T8AR in stock
The bearing F-87920-100-T8AR mainly used for the high speed extruder machine gearbox shaft.
It consisit of the washer ring and housing ring and cage with roller part.
| Bearing factory Number | F-87920-100-T8AR | ||||||||||||||||||||||||||
| Item code | F-87920.100.T8AR | ||||||||||||||||||||||||||
| Inner diameter d | Standard size | ||||||||||||||||||||||||||
| Tandem stages number | eight row stages | ||||||||||||||||||||||||||
| Inner diameter D | Standard size | ||||||||||||||||||||||||||
| Inner diameter B | Standard size | ||||||||||||||||||||||||||
| Cage type | Nylon or Steel or Brass Standard Cage | ||||||||||||||||||||||||||
| Precision grade | Standard precision | ||||||||||||||||||||||||||
| Bearing Material | High quality bearing steel | ||||||||||||||||||||||||||
| Description | cylindrical roller thrust bearing | ||||||||||||||||||||||||||
| UPC/HS code | 8482500090 | ||||||||||||||||||||||||||
|
T4AR
|
The Axial Forces Are Supported By A four-Stage Tandem Bearing T4AR Combined With An Axial Cylindrical Roller Bearing Of Series 894
|
||||||||||||||||||||||||||
| Application |
gearboxes for single and twin screw extrudes in the rubber and plastics industry. deep hole drilling equipment friction welding machines.
|
Tandem Bearings Type
1. Basic Type: The bearing adopts elastic spacer to connect the shaft washer,housing washer, roller and cage assembly. The components of this Thrust Bearings are demountable. The user should assemble or dismount the bearing meticulously according to our guide book.
2. Shaft Type: The bearing is made by penetrating an axis through the inner bore of basic type bearing and fastening the bearing to the axis by locking collar/snap ring. The components of this type bearing are inseparable. Shaft type tandem bearing is variational structure of basic type.
3. Multi-stage cylindrical roller thrust bearing (sleeve type) locking collar is made by covering a sleeve to the external of the basic type multi-stage cylindrical roller thrust bearing. It is also inseparable,and is assembled and disassembled as a whole.
