HC7017-EDLR-T-P4S-UL Spindle bearing,HC7017-EDLR-T-P4S-UL bearing direct lub design,stock
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
Spindle bearings HC7017-EDLR-T-P4S-UL |
|
| adjusted, in pairs or sets, contact angle α = 25°, with ceramic balls, restricted tolerances,direct lubrication design, P4 Precisn grade, in stock, FAG original package |
Description: Machine tool main spindle bearing
Type: HC7017-EDLR-T-P4S-UL bearing Machine tool main spindle bearing
Dimension: 85x130x22 mm/Metic
ID(inner diameter)/Bore:85 mm
OD(outer diameter):130 mm
Width/Height/thickness:22 mm
Quantity: One Bearing
The Number or ball: One
Lubrication: Oil or Grease
The forging material:GCr15SiMn GCr15, Chrome steel
The cage type: Laminated fabric
The package: standard export wooden case or carton boxes.
the following are the FAG HC7017-EDLR-T-P4S-UL main technology data:
|
Products name |
HC7017-EDLR-T-P4S-UL FAG main spindle bearing |
|
Made in |
Germany |
|
dimensions |
85x130x22mm |
|
Inner diameter |
85mm |
|
Outer diameter |
130 mm |
|
Height |
22mm |
|
Precision Rating |
P4 |
|
Quality standard |
DIN620 |
|
basicload rating(KN) |
Cr:29 KN |
|
Cor:15 KN |
|
|
Limiting Speed (r/min) |
Grease:17000 r/min |
|
Oil:26000 r/min |
|
|
Weight |
0.91 kgs |
|
The forging material |
Chrome steel |
|
The package |
Export Standard carton |
|
The delivery time |
In stock |
The Inner ring and outer ring hardness: 58-62HRC
The manufacture process including: Lathe process, Heat treatment process, Grinding process, Assembly process and final inspect process and on on.
The package: standard export wooden case or FAG standard carton boxes.
JinHang Precision Bearing mainly export high quantities FAG HC7017-EDLR-T-P4S-UL Bearing and relative products, we have huge stocks for HC7017-EDLR-T-P4S-UL bearing and relative items, we supply high quality FAG HC7017-EDLR-T-P4S-UL Bearing with reasonbable price or we produce the bearings along with the technical data or relative drawings, It's priority to us to supply best service to our clients. If you are interested in FAG HC7017-EDLR-T-P4S-UL Bearing, please email us :lyjh@lyjhbearing.com so we will contact you directly.
If you want to know more, please contact us as follows:
JinHang Precision Bearing Co.,Ltd
www.chinajhbearing.com www.lyjhbearing.com
E-mail: lyjh@lyjhbearing.com
MSN: lyjhbearing@hotmail.com
Skype: million556
