FAG Original HCB7226-C-T-P4S machine tool main spindle bearing:130x230x40mm,ceramic ball

Large Image : FAG Original HCB7226-C-T-P4S machine tool main spindle bearing:130x230x40mm,ceramic ball

Product Details:

Place of Origin:	Germany
Brand Name:	FAG or OEM
Certification:	Quality certificate
Model Number:	HCB7226-C-T-P4S

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Price:	Negotiation
Packaging Details:	Carton or standard export wooden case
Delivery Time:	in stock, if Ex-stock, It will need 5- 8 days
Payment Terms:	T/T,L/C
Supply Ability:	1000 PCS/Month

Contact Now

Detailed Product Description

Precision Rating:	P4 P5 P6 P0	Seals Type:	No Seal
Number Of Row:	Single Row

HCB7226-C-T-P4S Machine tool main spindle bearing with super precision bearing,HCB7226-C-T-P4S Bearing is a popular item that could be used in different application, the dimensions are 130x230x40 mm , HCB7226-C-T-P4S spindle Bearing with adjusted, in pairs or sets, contact angle α = 15°, restricted tolerances,ceramic ball bearing

Item: HCB7226-C-T-P4S Smachine tool main spindle bearing

Type: ball bearing or angular contact ball bearing

Material:GCr15,GCr15SiMn, Chrome steel

Dimension: 130x230x40 mm,

ID(Inner diameter) bore:130 mm metric size

OD(Outer diameter) bore:230 mm metric size

Width/Height/Thichkness:40 mm metric size

Quantity: one bearing

HCB:Hybrid standard ceramic balls.

C:Angular contact :15 degree

T: Laminated fabric guidance on outer ring

P4S:FAG Standard better than P4 to DIN620
