B7019-C-T-P4S-UL main spindle bearing 95x145x24mm,B7019.C.T.P4S.UL ball bearing,stock

Large Image : B7019-C-T-P4S-UL main spindle bearing 95x145x24mm,B7019.C.T.P4S.UL ball bearing,stock

Product Details:

Place of Origin:	Germany
Brand Name:	FAG or OEM
Certification:	Quality certificate
Model Number:	B7019-C-T-P4S-UL

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Price:	Negotiation
Packaging Details:	Carton or standard export wooden case
Delivery Time:	in stock, if Ex-stock, It will need 5- 8 days
Payment Terms:	T/T,L/C
Supply Ability:	1000 PCS/Month

Contact Now

Detailed Product Description

Precision Rating:	P4 P5	Seals Type:	No Seal
Number Of Row:	Single Row

FAG bearings B7019-C-T-P4S-UL adjusted, in pairs or sets, contact angle α = 15°, restricted tolerances
d: 95mm D: 145mm B: 24mm
Type:	B	Standard Steel balls
Dimension series:	70	Medium series
Dimension(dxDxh)		95x145x24mm
Contact angle:	C	C =15° E = 25°
Cages:	T	Plastic fiber cage, outer ring guided
Precision:	P4S	P4S FAG standard, reference to DIN620, higher than P4
Bearing arrangement:	U	single bearing, universal assemble
Preload:	L	light preload

B7019-C-T-P4S-UL High Precision Ball Bearing B7019.C.T.P4S UL Machine tool main spindle bearing

B7019-C-T-P4S-UL FAG High Speed Angular Spindle Bearing, Ball Bearing is Super precision Angular with 15 degrees contact angle and Phonetic cage, bearing is P4 quality and made in Germany

Item: B7019-C-T-P4S-UL FAG Ball Bearing,FAG machine tool main spindle bearing

Type: FAG Angular Spindle Ball Bearing

ball: steel ball

Quality: P4 Grade

Dimensions: 95mm x145mm x24mm /Metric

ID (inner diameter)/Bore: 95mm

OD (outer diameter): 145mm

Width/Height/thickness: 24mm

Size:95 x 145 x 24mm

Quantity: One Bearing

Dynamic load rating Cr: 81000 N

Static load rating Cor: 54000 N
