NU 1022 ML bearing with standard cage,dimension:110x170x28mm
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Precision Rating: | P5 P6 P0 | Seals Type: | No Seal |
|---|---|---|---|
| Number Of Row: | Single Row |
Description: Single row cylindrical roller bearing
Type: cylindrical roller bearing NU 1022 ML
Dimension: 110x170x28 mm/Metic
ID(inner diameter )/Bore: 110 mm
OD(outer diameter):170 mm
width/Height/thickness(B): 28 mm
The package: standard export wooden case or carton boxes.
|
Basic Dimensions(mm) |
Bearing Designations |
Bearing ratings (KN) |
Weight |
|||
|
d |
D |
B |
|
Cr |
Cor |
(KGS) |
|
110 |
170 |
28 |
NU 1022 ML |
128 |
166 |
2.3 |
The Bearing NU 1022 ML Applications:
The NU 1022 ML cylindrical roller bearing will working application: Cable Stranders,Worm gear, Screw Drives, Turbine engine mainshafts, Transmissions, large-size generators, machine tool spindles, axle boxes,bent axles of diesel engines, gearboxes, Mechanical presses, Electrical motors, Pumps and compressors, Traction motors for railway vehiches, Axle boxes for railway vehicles, Steel mills, And so on.
