NNU4964MAW33 cylindrical roller bearing dimension 320x440x118 mm for Wheel-end planetaries

Two-row cylindrical roller bearing NNU4964MAW33  has additional radial load-carrying capability compared to single row cylindrical roller bearing.It designed to ISO Specified interchangeable dimensions. Sold as complete assembly.

The cylindrical roller bearings NNU4964MAW33 has outer rings with solid ribs and lubrications grooves and holes on outer rings, one solid brass cage

The NNU4964MAW33 cylindrical roller bearing description as follows:

Name		Double/tow row cylindrical roller bearing NNU4964MAW33
Bearing type		NNU4964MAW33
Dimension		320x440x118 mm
ID(inner diameter)/Bore		320 mm
OD(outer diameter)		440 mm
Width/Height/thickness		118 mm
Load Rating	Static	2660 KN
	Dynamic	1270 KN
Speed Ratings	Oil	790 RPM
	Grease	710 RPM
Weight		54 KGS
Delivery time		In stock, If ex-stock, the manufacture time about 15-20 days
package		Standard export wooden case
Quality standard		I S O 2 4 6/ GB/T 283
Material		GCr15 GCr15SiMn
HS Code		8482500090



JinHang Precision Bearing mainly  export precision cylindrical roller bearing  Timken NNU4964MAW33 Bearing and relative products, we have huge stocks for NNU4964MAW33   bearing  and relative items, Also if ex-stock, the best deliver time about 15-20 days. we produce the bearings along with the technical data or relative drawings, It's priority to us to supply best service to our clients. If you are interested in  NNU4964MAW33  Bearing, please email us :lyjh@lyjhbearing.com    so we will contact you directly. Thanks for your trust!



Our team advantage:
We have 70 employees, with 10 experienced engineers and professional technicists. The most of Engineer from LYC and ZWZ brand factory, they had owned produce and design and after sales experienced to design the bearing.We can also design the drawing according to the bearing work condition to meet the customer requirement.

Manufacturing ability:
Equipped with advanced manufacturing CNC Machine and test instruments to insure the accurate tolerance , all bearings are of uniform marking and packing with superior quality, reasonable prices and perfect services. Meanwhile we can make the module to test the mounting hole.
Quality control:
All the bearing from the forging to assembly process,It will need to inspect step.For the bearing forging we will need to test the size and hardness and surface, for the lathe process and grinding process,first it will need to check by the worker ,and then the professional inspector will checking the size and accurate,The last step the monitor will inspect the size. It can insure zero defect.
Service:
It can calculate the load curve.
Can offer assembly drawing based on the bearing working condition
Can offer pre- sale ,sale and after sale service



cylindrical roller bearings effectively reduce friction and
help transmit power in applications like:
• Power generation
• Oil fields
• Crop shears
• Gear drives
• Hoists
• Metals construction
• Mining
• Aggregate processing
• Pumps
• Rolling mills
• Wheel-end planetaries
• Wind energy
• Other industrial equipment
