supply Crossed roller bearing RU124 sample 80X165X22MM quality assurance,in stocks





Crossed roller bearing RU124G Belongs to Model RU integrated inner/outer ring type, the mounting holes are provided, this model doesn’t require a presser flange or housing.  In addition,because it has an integrated inner/outer ring structure and is equipped with washers,Its performance is minimally affected by the mounting procedure, ensuring stable rotation accuracy and torque. This model can be used for both inner-ring rotation and outer-ring rotation.

Name: RU124G Bearing or RU124G roller bearing or RU124G Crossed roller bearing, The bearing RU124G shaft diameter:80mm,

Dimension(dxDxB):80X165X22MM

Inner diameter (d):80mm

Outer diameter(D):165mm

Width(B):22mm

Weight:2.6kgs

Radial Basic load rating: C:33.1 KN,Co:50.9 KN

Precision grade: P2 P4 P5 class

Material:GCr15

Delivery time: in stock, after getting the order, within 2 days will send the customer

Shipping term: By DHL or UPS or Fedex or TNT or customer required.

RU124 crossed roller bearing Installation step as following:

1.Inspect the parts before installing:Clean bearing bracket,main axle or other parts to remove dirt or grease.

2.Place the bearing into the bearing bracket and main axle:To match the design clearance ,keep the bearing horizontal and insert the bearing into the bearing bracket or axle.If it is hard to install,use a rubber hammer to slightly hit every part of the bearing,so that the bearing can be attention to the hitting force is too large.Afterwards,the matching status of bearing and basic face can be examined by checking the noise.For a interference fit,use heating or cooling to expand or shrink the parts for ease of installation. Be sure the bearing temperature does not exceed 80℃ . If the split inner or outer ring is acentric, please loosen the blots slightly and rotate the monolithic ring to adjust the concentricity of split ring, so that the bearing can be fit in the bracket.

3.Install the mounting disc:Place the mounting disc onto the bearing and align the screw holes, Screw all the bolts in the holes first and follow the orders show in below diagram when tightening bolts in diagonally opposite sequence,Do not tighten bolts randomly.
